Weird science: Robot that grips without touching being developed in Switzerland

ETH Pioneer Fellow Marcel Schuck is developing a robotic gripper that can manipulate small and fragile objects without touching them. The technology is based on sound waves.

The small installation that Marcel Schuck has assembled on his workbench at ETH university in Zurich, Switzerland, is reminiscent of a school physics lesson: an arrangement, comprising two semi-spheres and resembling a pair of headphones, is connected to a circuit board carrying microchips. He is using the assembly to demonstrate a physical effect. A small sphere hovers between the two semi-spheres, held up by ultrasound waves. "This phenomenon is known as acoustic levitation," the scientist explains.

[Photo credit: ETH Zurich/Stefan Weiss]



As part of his ETH Pioneer Fellowship, the former ETH doctoral student is currently developing a method that makes it possible to lift and manipulate small objects entirely without touching them. This could be particularly relevant in situations where damage to small components costs money, such as in the watchmaking or semiconductor industries.

Conventional robotic grippers sometimes damage fragile objects. To counter this, soft, rubber-like grippers can be used. Although these cause no damage, they are easily contaminated, like a well-used rubber eraser. Additionally, these soft robotic grippers only offer limited positioning accuracy.

"Gripping without touching" is the principle behind Schuck's project called "No-Touch Robotics." The technology is based on an effect that has been exploited for more than 80 years and was first used in space exploration. Ultrasound waves generate a pressure field that humans cannot see or hear. Pressure points are created as the acoustic waves overlay each other, and small objects can be trapped within these points. As a result, they seem to float freely in the air in an acoustic trap.

Marcel Schuck and his "no-grip" gripper. [Photo credit: ETH Zurich/Stefan Weiss]



The installation in his laboratory is the prototype for the product that Schuck wants to develop: an electronically controlled robot gripper using ultrasound. The 31-year-old scientist has fitted numerous small loudspeakers into the two semi-spheres, created using a 3D printer. The associated software allows Schuck to control the loudspeakers such that the pressure points can be moved around. The goal is to change their position in real time without the suspended object falling to the ground. This particular aspect is being researched by ETH doctoral student Marc Rothlisberger, who shares a lab at the Technopark Zurich with Schuck and Christian Burkard, a master's student.

Just using the existing technology, the scientists are able to move various small objects through space. The software adjusts the gripper to the shape of the object to be lifted, and a robot arm then transports the object to the target destination.

The principle of gripping without touching also has an economic benefit: When working with a conventional robot, a different gripper is required for almost every new shape. The acoustic gripper eliminates the need for an extensive set of expensive high-precision grippers.

It is not even necessary for the robot arm itself to be extremely precise. "The exact positioning is determined by the acoustic waves controlled by the software," Schuck says.

[Photo credit: ETH Zurich/Stefan Weiss]



Initially, Schuck wants to use the funding from his ETH Pioneer Fellowship to determine how robot grippers are deployed in practice. "The main aim is to explore the potential fields of application and open doors within industry," Schuck says.

The innovation is likely to be of interest to the watchmaking industry, where highly precise micromechanics is essential for handling expensive, minute components. Toothed gearwheels, for example, are first coated with lubricant, and then the thickness of this lubricant layer is measured. Even the faintest touch could damage the thin film of lubricant. Microchip production might be another attractive market for Schuck's technology.

Schuck is using some of the 150,000 Swiss francs ($157,000) from the fellowship to create a type of development kit for potential clients. This contains a robot gripper, control software, and instructions. Schuck stresses that he still does not know how the end product will look.

"That depends on the feedback I get from industry," he says. He hopes he will find a few interested parties who will collaborate with him on the further development of the acoustic gripper.

On the one hand, this should help to satisfy existing market needs. On the other hand, Schuck is keen for the technology to work not just in the laboratory, but in the real world. If he can manage this by the spring of 2021, Schuck figures he should be able to establish a start-up based on his innovative business idea.

Source: ETH (Eidgenossische Technische Hochschule Zurich)
