Army bringing Detroit military muscle, hybrid efficiency to Chicago Auto Show

By John W. Wray, RDECOM

The U.S. Army has sent two concept hybrid vehicles to the Chicago Auto Show to showcase its latest energy-efficiency efforts that can save money, address environmental concerns, and, most importantly, save Soldiers' lives. The show, which kicked off Feb. 10, will run the full week until Feb. 19.

The U.S. Army Tank Automotive Research, Development and Engineering Center, known as TARDEC, will display two Clandestine Extended Range Vehicles, or CERVs, from its Detroit Arsenal-based headquarters at the Chicago Army Recruiting Battalion display.

Command Sgt. Maj. Hector Marin, U.S. Army Research, Development and Engineering Command, rides in a Clandestine Extended Range Vehicles (CERV) at the Army Strong Zone Jan. 6, 2011, in San Antonio, TX. [Photo Credit: Tom Faulkner]









CERVs are lightweight, diesel-electric hybrid prototypes with a top speed of 80 mph. Designed for reconnaissance, targeting, and rescue missions, CERVs have silent-run capabilities of 8 miles. Each CERV can ascend a 60% grade and has a torque rating of 5,000 lb.

The CERVs boast a 25% fuel savings compared with conventional vehicles. TARDEC developed the vehicles with California-based Quantum Technologies.

"TARDEC's mission remains unchanged; bring the newest innovations and technology that support our troops against an ever-evolving and changing enemy threat," says Derhun Sanders, TARDEC associate director of communications. "Undoubtedly, these are some of the Army's greenest vehicles and the kind of technology that can meet our nation's energy security demands."

In terms of Soldier safety, Sanders points to a recent Army Energy Security Task Force report stating a 1% improvement in fuel economy results in 6,444 fewer Soldier trips on fuel convoys. A significant number of American casualties in Iraq and Afghanistan have resulted from guarding fuel convoys.

CERVs are being tested around the country as the finishing touches are being put on the Army's newest lab, the 30,000-sq-ft Ground Systems Power and Energy Lab, or GSPEL, which will open April 11. The lab is located at the Detroit Arsenal.

GSPEL is an eight-labs-in-one, state-of-the-art research and development facility. GSPEL will serve as the cornerstone for the Army's next generation of power and energy initiatives, providing the Army with the cutting-edge laboratory space and equipment necessary to conduct research, development, modeling, simulation, and testing on military and commercial ground vehicles of all sizes and purposes from subsystem components to entire systems of systems.

Published February 2012
