How engineered crystals could help computers run on less power

A new material created by University of California, Berkeley, researchers could reduce the energy required to control advanced silicon transistors.

Computers may be growing smaller and more powerful, but they require a great deal of energy to operate. The total amount of energy the U.S. dedicates to computing has risen dramatically over the last decade and is quickly approaching that of other major sectors, like transportation.

In a study published online April 6 in the journal Nature, University of California, Berkeley, engineers describe a breakthrough in the design of a component of transistors -- the tiny electrical switches that form the building blocks of computers -- that could significantly reduce their energy consumption without sacrificing speed, size, or performance. The component, called the gate oxide, plays a key role in switching the transistor on and off.

"We have been able to show that our gate-oxide technology is better than commercially available transistors: What the trillion-dollar semiconductor industry can do today -- we can essentially beat them," said study senior author Sayeef Salahuddin, the TSMC Distinguished professor of Electrical Engineering and Computer Sciences at UC Berkeley.

This boost in efficiency is made possible by an effect called negative capacitance, which helps reduce the amount of voltage that is needed to store charge in a material. Salahuddin theoretically predicted the existence of negative capacitance in 2008 and first demonstrated the effect in a ferroelectric crystal in 2011.

University of California, Berkeley, engineers have created engineered crystal structures that display an unusual physical phenomenon known as negative capacitance. Incorporating this material into advanced silicon transistors could make computers more energy efficient. [Credit: Ella Maru Studio]









The new study shows how negative capacitance can be achieved in an engineered crystal composed of a layered stack of hafnium oxide and zirconium oxide, which is readily compatible with advanced silicon transistors. By incorporating the material into model transistors, the study demonstrates how the negative capacitance effect can significantly lower the amount of voltage required to control transistors, and as a result, the amount of energy consumed by a computer.

Bringing negative capacitance to real technology
State-of-the-art laptops and smartphones contain tens of billions of tiny silicon transistors, and each must be controlled by applying a voltage. The gate oxide is a thin layer of material that converts the applied voltage into an electric charge, which then switches the transistor.

Negative capacitance can boost the performance of the gate oxide by reducing the amount of voltage required to achieve a given electrical charge. However, the effect can't be achieved in just any material. Creating negative capacitance requires careful manipulation of a material property called ferroelectricity, which occurs when a material exhibits a spontaneous electrical field. Previously, the effect has only been achieved in ferroelectric materials called perovskites, whose crystal structure is not compatible with silicon.

In the study, the team showed that negative capacitance can also be achieved by combining hafnium oxide and zirconium oxide in an engineered crystal structure called a superlattice, which leads to simultaneous ferroelectricity and antiferroelectricity.

"We found that this combination actually gives us an even better negative capacitance effect, which shows that this negative capacitance phenomena is a lot broader than originally thought," said study co-first author Suraj Cheema, a postdoctoral researcher at UC Berkeley. "Negative capacitance doesn't just occur in the conventional picture of a ferroelectric with a dielectric, which is what's been studied over the past decade. You can actually make the effect even stronger by engineering these crystal structures to exploit antiferroelectricity in tandem with ferroelectricity."

The researchers found that a superlattice structure composed of three atomic layers of zirconium oxide sandwiched between two single atomic layers of hafnium oxide, totaling less than two nanometers in thickness, provided the best negative capacitance effect. Because most state-of-the-art silicon transistors already use a 2-nanometer gate oxide composed of hafnium oxide on top of silicon dioxide, and since zirconium oxide is also used in silicon technologies, these superlattice structures can easily be integrated into advanced transistors.

To test how well the superlattice structure would perform as a gate oxide, the team fabricated short channel transistors and tested their capabilities. These transistors would require approximately 30% less voltage while maintaining semiconductor industry benchmarks and with no loss of reliability, compared to existing transistors.

"One of the issues that we often see in this type of research is that we can we can demonstrate various phenomena in materials, but those materials are not compatible with advanced computing materials, and so we cannot bring the benefit to real technology," Salahuddin said. "This work transforms negative capacitance from an academic topic to something that could actually be used in an advanced transistor."

Source: University of California, Berkeley

Published May 2022
