U.S. Air Force selects Raytheon Missiles & Defense, Northrop Grumman to deliver first hypersonic air-breathing missile

[Image credit: Raytheon]





Raytheon Missiles & Defense, in partnership with Northrop Grumman, has been selected to develop the Hypersonic Attack Cruise Missile (HACM) for the U.S. Air Force (USAF). HACM is a first-of-its-kind weapon developed in conjunction with the Southern Cross Integrated Flight Research Experiment (SCIFiRE), a U.S. and Australia project arrangement.

Under this contract, the Raytheon Missiles & Defense and Northrop Grumman team will deliver operationally ready missiles to the USAF.

The Hypersonic Attack Cruise Missile is an air-breathing, scramjet-powered munition. Scramjet engines use high vehicle speed to forcibly compress incoming air before combustion, which enables sustained flight at hypersonic speeds -- Mach 5 or greater. By traveling at these speeds, hypersonic weapons, like HACM, are able to reach their targets more quickly than similar traditional missiles, allowing them to potentially evade defensive systems.

"The Hypersonic Attack Cruise Missile creates a new class of strategically important weapons for the U.S. military," said Mary Petryszyn, corporate vice president and president, Northrop Grumman Defense Systems. "Our scramjet propulsion technology is ushering in a new era for faster, more survivable, and highly capable weapons."

Raytheon Technologies and Northrop Grumman have been working together since 2019 to develop, produce, and integrate Northrop Grumman's scramjet engines onto Raytheon's air-breathing hypersonic weapons. Their combined efforts enable both companies to produce air-breathing hypersonic weapons, the next generation of tactical missile systems.

Source: Raytheon

Published November 2022
