3,000 mpg? Freudenberg-NOK Sealing Technologies helps U-of-M Supermileage team push for ultimate fuel efficiency

Sitting off a main road that runs through the University of Michigan's (U of M) North Campus in Ann Arbor is a large industrial garage with an impossibly bright roof. On a recent windy afternoon, four engineering students sit in one of the building's mechanical bays staring at a car.

The car is a virtual pod, a one-occupant carbon fiber shell balanced on three wheels. It has just enough room for a small driver, small engine, and somewhat touchy steering system. The students, members of U of M's Supermileage Team, acknowledge that their next vehicle will brag improvements, including better steering.

But steering may be secondary because the real challenge these students face is how to squeeze more than 3,000 miles from a single gallon of fuel. The team is one of the newest participating in the SAE International's Supermileage competition. As one of its primary sponsors, FNST is offering the financial and professional resources needed to cross the finish line.

Freudenberg-NOK Sealing Technologies is sponsoring the U of M Supermileage Team. From left: Andy Dun (blue tee), junior, mech. eng.; David Coons, junior, mech. eng.; Rory Pawl, dir., FNST Future Technology; Mike Rowe, FNST strategic product development manager, Technology; Karan Jain, junior, mech. eng.; and John Rockwell, junior, mech. eng. [Photo: 2013 TIF Photographic LLC, Edward Llewellyn Ochal.]









"We regularly collaborate with industry partners to develop technologies that address issues like fuel economy and powertrain efficiency," says Dr. Luis Lorenzo, vice president, Advanced Product Engineering, FNST. "Our partnership with U of M's Supermileage Team allows us to build communications and collaboration with the next generation of engineers. It's a fundamental part of our approach to leadership and future growth."

FNST's sponsorship is also fundamental to the U of M team. Not only will the students benefit from professional assistance provided by Mike Rowe, FNST strategic product development manager, Technology, and Rory Pawl, FNST director, Future Technology, they will also tap into some of company's most advanced component technologies.

Among the FNST products that Rowe has identified for use on the Supermileage Team's new car are ultra-low friction crankshaft seals; self-fusing silicone tape for electrical connections, cable management, and emergency repairs; new body seals; low-friction valve stem seals; and even bearing grease and mold release agents from Freudenberg sister companies Kluber Lubrication and Chem-Trend.

"This program is a great fit with the kinds of research and development activities our company is pursuing," Rowe says. "We regularly seek breakthroughs in fuel economy technology. This program will allow us to tap into innovations and frankly, is going to be a lot of fun."

"We're new to engineering, and working with a top-notch company like Freudenberg is extremely helpful in clarifying our ideas and discussing technologies," says David Coons, a mechanical engineering student and the team's chief engineer. "When we're not sure how to do something, they fill in the gaps and offer us advice and guidance."

Going for 3,000 mpg: U of M mechanical engineering students (from left) John Rockwell, Karan Jain, Andy Dun, and David Coons. [Photo: 2013 TIF Photographic LLC, Edward Llewellyn Ochal]









The SAE International Supermileage competition requires university engineering and technology students to develop and construct a single-person, fuel-efficient vehicle powered by a four-cycle engine. Vehicles run a specified course, and the vehicle that obtains the highest miles-per-gallon rating, in combination with design points, wins the challenge. All of the vehicles are powered by a one-cylinder, Briggs & Stratton engine that the teams uniquely modify to push efficiency and fuel savings.

More than 24 collegiate teams will participate in this year's race taking place in Marshall, MI, in June. The 2012 winner was Penn State University, Behrend College Pennsylvania, with a winning entry that logged the equivalent of 1,485 mpg. For more information about the race, click here.

The U-of-M team will test drive its 2013 car in April in the Shell Eco Marathon in Houston as a prelude to the SAE International Supermileage event. With a best run of 2,188.6 mpg equivalency, the team from Mater Dei High School in Evansville, IN, won the first-place prize in the Shell Eco Marathon last year in Houston.

For their part, Coons and his teammates admit that their car will not be a blueprint for America's next family sedan. But the experience of pushing boundaries to achieve something they thought was impossible will remain with them throughout their lives, Coons says.

Source: Freudenberg-NOK Sealing Technologies

Published February 2013
