Henkel opens world's largest adhesives factory in China

Henkel opened the world's largest adhesives factory in Shanghai on September 18, 2013. With this new production facility, the company is expanding its production capacity in a major emerging market and plans to deliver its innovative adhesive technologies more quickly to the growing number of customers based in China and the Asia-Pacific region.

The new factory, which is also known as the "Dragon Plant" at Henkel, comprises 150,000 m² of space and is now the central production site for industrial adhesives in China and the Asia-Pacific region. Customers being served by the new adhesives plant include enterprises in the automotive industry and various consumer goods sectors. Annual output is forecast to reach up to 428,000 metric tons of adhesives.

"This new adhesives factory will contribute significantly to the achievement of our strategy 2016: It will enable our adhesives business to expand and leverage its global reach, and win market share in emerging markets," says Kasper Rorsted, chairman of the Management Board of the Henkel Group. The inaugural ceremony was attended by numerous Chinese politicians and businesspeople and also by Dr. Simone Bagel-Trah, chairwoman of the Supervisory Board and of the Shareholders' Committee. Henkel is already generating 45 percent of its total sales in emerging markets, and 55 percent of its employees are based in these countries. One of Henkel's financial targets for the year 2016 is to increase the sales generated in emerging markets to 10 billion euros while aiming for total sales of 20 billion euros.

Henkel has invested more than 50 million euros in the plant and will employ about 600 people there.

China has already advanced to become the largest car market in the world, with a rapidly expanding domestic production base. The country is also one of the major producers of sports equipment and electronic products. In these and many other industries, adhesives are being used more and more as they make the products lighter and enhance their performance while helping to make production processes more sustainable.

The "Dragon Plant" is a model for sustainability and efficiency. Compared to a traditional production plant, it uses only half the amount of water thanks to condensed water-recovery systems, while recycling has reduced the volume of packaging materials by 60 percent, and electricity usage for factory lighting has been cut by 90 percent due to special translucent roofs that let the daylight in. There is also a system for recovering waste heat, and the factory includes innovative filling equipment designed to prevent leaks and spills of adhesives.

As a supplier to many different industries, Henkel already opened its first production facility in China back in 1990, just two years after entering the market. From that first factory, Henkel served industrial customers who had begun at this early stage to establish their own manufacturing operations in China. Ever since then, Henkel has continued to produce adhesives in this East Asian country with constantly rising sales.

Source: Henkel

Published October 2013
