Continental to launch production of short-range radar sensors in the U.S.

International automotive supplier Continental will launch production this month of short-range radar sensors for advanced driver assistance systems at its plant in Seguin, Texas.

Continental has experienced rapid growth in the business with sensor technologies like camera, lidar, and radar. Since production began in 1999, Continental has turned out more than 10 million sensors, 4.5 million last year alone.

Continental's Rear Cross Traffic Alert (RCTA) system can help to avoid accidents with crossing vehicles when reversing out of a parking space.





Next year should see the 26-million mark, some 10 million of which will be radar sensors (short- and long-range radars). However, cameras -- mono, stereo, and camera systems for 360-degree surround detection -- are also booming. Lane Departure Warning, Intelligent Headlamp Control, plus such functions as Traffic Sign Recognition and camera-based parking assistant systems are becoming increasingly popular in all classes of cars.

A single line will handle production initially, but additional lines are in preparation to satisfy the demand of OEMs manufacturing in the United States. "We plan to produce some 3 million short-range radar sensors in Seguin in 2016," says Karlheinz Haupt, head of the Advanced Driver Assistance Systems (ADAS) business unit of Continental's Chassis & Safety Division. "The numbers say something about how rapidly demand is rising for short-range radar functions like Blind Spot Detection or parking assistant systems. Legislation is a driving force but also our customers' desire for increased safety and comfort is providing a major impetus."

Short-range radar sensors by Continental are indispensable to Blind Spot Detection (BSD) and Rear Cross Traffic Alert (RCTA). The BSD feature warns drivers of cars lurking in the blind spot, making passing and lane changes safer and more manageable, both in city traffic and in highway driving. The RCTA feature detects crossing traffic behind the vehicle while the car is backing out, helping to avoid accidents that can often result in serious injuries.

The Blind Spot Detection (BSD) function warns the driver when there are vehicles in the blind spot of the side-view mirror.





Advanced driver assistance systems represent a key technology on the road to accident-free driving (Vision Zero). Vision Zero will become reality in three steps, beginning with no fatal accidents, followed by no injuries and, ultimately, no accidents at all. "Advanced driver assistance systems and proven sensor technology are a major component of automated driving. Highly or fully automated driving can only become a reality through high-performance sensors and a reliable, accurate model of the vehicle surrounding," says Haupt. From a technological perspective, automated driving is a further development in driver assistance system technology that Continental has already started to pursue.

Source: Continental

Published April 2014
