Alcoa announces jet engine aluminum first in $1.1B supply agreement with Pratt & Whitney

Leading aerospace manufacturer Alcoa recently announced a 10-year, $1.1 billion agreement with Pratt & Whitney for state-of-the-art jet engine components. Under the deal signed at the Farnborough Air Show in mid-July, Alcoa will supply key parts for Pratt & Whitney's engines, including the forging for the first-ever aluminum fan blade for jet engines. The forging was developed for Pratt & Whitney's PurePower engines using an advanced aluminum alloy and a proprietary manufacturing process. Alcoa is also developing a fan blade forging for the PurePower engines using its most advanced aluminum-lithium alloy.

Pratt & Whitney's PurePower engine. [Photo courtesy of Pratt & Whitney]





"We're going where no materials scientist has gone before," says Alcoa Chairman and Chief Executive Officer, Klaus Kleinfeld. "Combining Alcoa's proprietary alloys and unique manufacturing processes with Pratt & Whitney's design, we cracked the code on forging an aluminum fan blade that is lighter and enables better fuel efficiency."

Under the billion-dollar deal, Alcoa will supply components for Pratt & Whitney's PurePower PW1000G, V2500, GP7000, and several other regional jet and military engines. The unique Geared Turbofan architecture of the PurePower engine allows for aluminum alloys to be used in the Pratt & Whitney-designed fan blades, making the engine lighter, as well as more fuel and cost efficient. The PurePower engine will be used to power some of the world's highest-volume aircraft, including the next-generation Airbus A320neo.

"We are able to provide our customers with double-digit improvements in fuel efficiency, environmental emissions, and noise," says Paul Adams, president, Pratt & Whitney.

In the PurePower PW1000G engine family, a state-of-the-art gear system separates the engine fan from the low-pressure compressor and turbine, allowing each of the modules to operate at their optimum speeds. This enables: 1. an increase in the diameter of the fan, and 2. the low-pressure compressor and turbine to operate at a high speed. The increased efficiency also translates to fewer engine stages and parts for lower weight and reduced maintenance costs. The large, lightweight fan moves more than 90 percent of the air around the core, delivering a very quiet engine with very low fuel burn. The larger fan diameter also opened the door to materials beyond titanium and composites.

Alcoa plans to use aluminum and aluminum-lithium from its Pittsburgh, PA, and Lafayette, IN, facilities for the front fan blades, which will be produced using proprietary manufacturing processes at its Cleveland, OH, plant. Several of Alcoa's facilities including La Porte, IN; Whitehall, MI; Dover, NJ; and Wichita Falls, TX, will supply the blades, vanes, and structural components produced using nickel-based superalloys, titanium, and aluminum.

Source: Alcoa

Published August 2014
