Swedish Steel Prize finalists announced for 2015

It's that time of year again. Fall means it's time for the Swedish Steel Prize jury to announce the finalists in its yearly competition. Four finalists have been chosen, and the winner will be announced at a ceremony in Stockholm on Nov. 19, 2015. This year, SSAB received a total of 77 applications from 28 countries. The competition attracted the highest number of applications from the heavy transportation industry, although entries were submitted from a broad spectrum of segments.

The aim of the Swedish Steel Prize is to inspire, encourage, and disseminate knowledge about high-strength steel and the possibilities for developing lighter, safer, and more environmentally friendly products. SSAB, a Nordic and US-based steel company with a global reach, instituted the Swedish Steel Prize in 1999.

The winner will receive an award of SEK 100,000 (over $15,000), a statuette, and some envy from industry peers, because this is a very highly regarded prize. The prize ceremony will conclude with a two-day-long event, where hundreds of international representatives from the engineering and industrial sectors will participate in plant visits and seminars.

Belaz, maker of world's largest dump truck, won the Swedish Steel Prize in 2014.

The jury has chosen innovations from the mining, forestry, and transportation industries. The finalists are:

-----------------------------------------------------------------------

Facil System, sugar cane shredder knives, Brazil
The new sugar cane shredder knives developed by Facil Systems have been bolted spirally onto the support at the axles. The solution saves energy and considerably prolongs the service life of the knives. Founded in 1986, Facil Systems is based in the Sao Paolo region, but its products are not only sold in Brazil, but also exported to the rest of South America and to India.

-----------------------------------------------------------------------

Milotek Pty Ltd, rail transportation system, South Africa
Milotek has developed a completely new type of rail transportation system for heavy transportation. The Futran System is an environmentally aware, suspended transportation system that provides a cost-effective, flexible alternative to traditional rail, truck, conveyor belt, and even underground mine haulage systems.

-----------------------------------------------------------------------

Ponsse Plc, forest harvester, Finland
Founded in 1970 in Vierema, Finland, Ponsse has systematically developed and launched a new generation of forest harvesters (Ponsse Scorpion), that benefits from the use of high-strength steels in the design of the chassis, crane arms, and cutter heads. Ponsse has focused particularly on operator ergonomics.

-----------------------------------------------------------------------

TEREX Cranes Germany, adaptable crane section (Boom Booster), Germany
Terex has created an adaptable crane section kit, the Boom Booster, to give its CC 8800-1 crane significantly increased lifting performance. The Boom Booster is attached as the lower part of the main boom of the crane and can also extend crane reach. High-strength steels are used in the Booster's cross-section solution.

-----------------------------------------------------------------------

Be on the lookout for the winner in the Nov. 24 issue of Designfax.

More information is available at www.ssab.com/en/SteelPrize/.

Source: SSAB

Published October 2015
