After falling into National Corvette Museum sinkhole, restoration of 1-millionth Corvette underway

Craftspeople and technicians at the General Motors Design Center in Michigan are painstakingly restoring the 1-millionth Chevrolet Corvette. The historic production vehicle was damaged nearly 16 months ago when a sinkhole opened up beneath the National Corvette Museum in Bowling Green, KY.

Chevy will spare no expense to restore this '92 Corvette, its 1-millionth production vehicle. [Photos by Bob Bubnis/National Corvette Museum for Chevrolet]





The white 1992 Corvette is a challenge because rather than build an all-new vehicle from the ground up, the workers are trying to preserve the original appearance of a production vehicle.

It is the second of three sinkhole-damaged Corvettes that Chevrolet has pledged to restore. The first, a 2009 Corvette ZR1 prototype known as the Blue Devil, was only lightly damaged and was returned to its original condition last fall. The National Corvette Museum will oversee the restoration of the third car, a 1962 Corvette.

Workers use a crane to recover the 2009 Corvette ZR-1 "Blue Devil" from the sinkhole at the National Corvette Museum. This car was the first to be lifted out of the hole.





A crane is used to remove the black 1962 Chevrolet Corvette from the sinkhole at the National Corvette Museum.





How it all went down
On Wednesday, Feb. 12, 2014, at 5:44 a.m., National Corvette Museum personnel were notified by their security company about the burglar alarm going off in the Skydome area of the museum. Upon arrival at the museum, a sinkhole measuring about 45-by-60 ft wide and 30 ft deep was discovered.

Security camera footage showing the Skydome floor's collapse has been viewed more than 8.5 million times on YouTube.

Eight historic Corvettes -- two on loan from GM and six owned by the museum -- were swallowed that day:

• 1993 ZR-1 Spyder (on loan)
• 2009 ZR1 "Blue Devil" prototype (on loan)
• 1962 Corvette
• 1984 PPG Pace Car
• 1992 1 millionth Corvette
• 1993 40th Anniversary Corvette
• 2001 "Mallett Hammer" Z06
• 2009 1.5 millionth Corvette.

On March 3, 2014, the 2009 Blue Devil was the first car recovered, and despite significant damage was started and driven out of the Skydome. The 1.5-millionth Corvette and Mallet Corvette were the last cars pulled from the sinkhole, on April 3 and April 9, respectively -- after workers were initially unable to find them amid the collapsed earth.

Source: Chevrolet

Published June 2015
