BAE Systems develops laser airspeed sensor for next-generation high-altitude aircraft

In an aviation first, British scientists in Chelmsford, U.K., have successfully ground tested a highly accurate laser airspeed sensor for use in the next generation of high-altitude aircraft. The technology aims to increase survivability while improving performance and fuel efficiency

The Laser Air Speed Sensing Instrument (LASSI), exhibited at the huge, biennial Farnborough International Airshow (held July 15-17 this year), sets itself apart from conventional methods because it accurately measures velocity even at low speeds.

BAE Systems' Laser Air Speed Sensing Instrument (LASSI).





Conventionally, air speed is determined using pitot tubes that protrude from aircraft and sense variations in air pressure with speed. Although usually heated, these tubes are vulnerable to blockage in icy conditions. They can also be damaged by collisions with birds and when the aircraft is on the ground.

Operating on the same principle as roadside speed guns, the new technique works by bouncing ultraviolet laser light off air molecules and measuring the change in "color" of the reflections caused by the Doppler Effect. In layman's terms, the further away from the ultraviolet light the reflection is, the faster the aircraft is travelling. Although invisible to the human eye, the detector can identify minute changes in color -- and these changes, in turn, indicate the aircraft's airspeed.

"LASSI is a ground-breaking piece of technology which is challenging the conventional method of measuring air speed," said Dr. Leslie Laycock, executive scientist at BAE Systems. "Conventional air data sensors which protrude from the sides of aircraft must be carefully located to work properly and are inaccurate at low airspeeds. LASSI can be located completely inside the aircraft and is accurate at low airspeeds. It can even measure negative air velocities. These features should ensure that the equipment is robust against damage, requires less maintenance, and is easier to operate at lower airspeeds."

"A significant benefit is that LASSI has the potential to detect air speed at a distance, meaning an aircraft could predict oncoming turbulence and change course accordingly," added Laycock.

BAE Systems has successfully tested LASSI in a low-speed wind tunnel and on ground vehicles. Engineers from the company predict the component technology could be miniaturized and be in use within the next five years. They are now investigating how it could be integrated in future aircraft.

BAE Systems says the other benefits/capabilities of the technology include, "the ability to ‘steer' the sensor will enable accurate vector measurements to be taken improving the control of flight. For military aircraft, LASSI will enable a reduction in the radar cross-section of the aircraft and hence improve its survivability in enemy territory. LASSI could also be used for alternative applications such as mapping the airflow around buildings and structures."

The company also says that there will be slight gains made in reducing drag on aircraft by removing the pitot tubes.

Source: BAE Systems

Published July 2016
