GE acquiring two 3D-printing companies for $1.4B, going into additive-manufacturing service biz

GE recently announced plans to acquire two suppliers of additive manufacturing equipment, Arcam AB [Sweden] and SLM Solutions Group AG [Germany], for $1.4 billion. Both companies will report to David Joyce, president and CEO of GE Aviation. Joyce will be tasked with leading the growth of these businesses in the additive manufacturing equipment and services industry. In addition, he will lead the integration effort and the GE Store initiative to drive additive manufacturing applications across GE.

Additive manufacturing (also called 3D printing) involves taking digital designs from computer aided design (CAD) software and laying horizontal cross-sections to manufacture the part. Additive components are typically lighter and more durable than traditionally manufactured parts because they require less welding and machining. Because additive parts are essentially "grown" from the ground up, they generate far less scrap material. Freed of traditional manufacturing restrictions, additive manufacturing dramatically expands the design possibilities for engineers. "Ultimately, as we develop more productive machines, we can build additive manufacturing ‘as a service' for our customers," said Joyce.

GE expects to grow the new additive business to $1 billion by 2020 at attractive returns and also expects $3 billion to $5 billion of product cost-out across the company over the next 10 years.

"Additive manufacturing is a key part of GE's evolution into a digital industrial company," said Jeff Immelt, chairman and CEO of GE. "We are poised to not only benefit from this movement as a customer, but spearhead it as a leading supplier."

In July, GE Aviation introduced into airline service its first additive jet engine component -- complex fuel nozzle interiors -- with the LEAP jet engine. The LEAP engine is the new, best-selling engine from CFM International, a 50/50 joint company of GE and Safran Aircraft Engines of France. More than 11,000 LEAP engines are on order with up to 20 fuel nozzles in every engine, thus setting the stage for sustainably high and long-term additive production at GE Aviation's Auburn, AL, manufacturing plant.

A 3D-printed fuel nozzle (top left of the part) for GE's LEAP jet engine. [Image credit GE Aviation]





Production will ramp up to more than 40,000 fuel nozzles using additive by 2020. GE Aviation is also using additive manufacturing to produce components in its most advanced military engines. In the general aviation world, GE is developing the Advanced Turboprop Engine (ATP) for a new Cessna aircraft with a significant portion of the entire engine produced using additive manufacturing.

The acquisitions
Arcam AB, based in Mölndal, Sweden, invented the electron beam melting machine for metal-based additive manufacturing, and also produces advanced metal powders. Its customers are in the aerospace and healthcare industries. Arcam generated $68 million in revenues in 2015 with approximately 285 employees. In addition to its Sweden site, Arcam operates AP&C, a metal powders operation in Canada, and DiSanto Technology, a medical additive manufacturing firm in Connecticut, as well as sales and application sites worldwide.

SLM Solutions Group, based in Lübeck, Germany, produces laser machines for metal-based additive manufacturing with customers in the aerospace, energy, healthcare, and automotive industries. SLM generated $74 million in revenues in 2015 with 260 employees. In addition to its operations in Germany, SLM has sales and application sites worldwide.

Arcam and SLM will bolster GE's existing material science and additive manufacturing capabilities. GE has invested approximately $1.5 billion in manufacturing and additive technologies since 2010. The investment has enabled the company to develop additive applications across six GE businesses, create new services applications across the company, and earn 346 patents in powder metals alone. In addition, the additive manufacturing equipment will leverage Predix (GE's cloud-based platform (PaaS) for Industrial Internet applications) and be a part of GE's "Brilliant Factory" initiative.

The additive effort will utilize GE's global ecosystem, but be centered in Europe. GE will maintain the headquarters locations and key operating locations of Arcam and SLM, as well as retain their management teams and employees. These locations will collaborate with the broader GE additive ecosystem including the manufacturing and materials research center in Niskayuna, NY, and the additive design and production lab in Pittsburgh, PA. They will also complement the technologies brought on by other key acquisitions such as Morris Technologies and Rapid Quality Manufacturing.

Source: GE

Published September 2016
