Airbus creates the first electric airplane race series: Air Race E

Airbus has announced a global partnership with Air Race E, the world's first electric airplane race set to launch its inaugural series in 2020.

Airbus is the Official Founding Partner of the race series. The competition aims to drive the development and adoption of cleaner, faster, and more technologically advanced electric engines that can be applied to urban air mobility vehicles and, eventually, commercial aircraft.

Air Race E will follow a format similar to the popular Air Race 1 series of the sport known as Formula One air racing. Eight electric-powered airplanes will race directly against each other on a tight 5-km circuit, just 10 m (33 ft) above the ground and at speeds faster than any land-based motorsport.

Air Race 1 pilots travel at speeds up to 450 kph (280 mph).

VIDEO: Air Race 1 intro video. Air Race E will be similar, but featuring electric planes.

"We want to motivate manufacturers to showcase their technologies across the full spectrum of electric propulsion systems and components," says Grazia Vittadini, chief technology officer of Airbus. "This partnership enables us to demonstrate our commitment to staying at the leading edge of electric propulsion and developing a new ecosystem."

Airbus will work alongside other Air Race E partners, including the University of Nottingham in the UK. The university is currently developing a prototype race airplane powered by an integrated electric motor, battery, and power electronics system. The plane will help shape the model and rules for the inaugural Air Race E race in 2020.

"This partnership is a significant milestone in the evolution of electric power in aviation, says Air Race E CEO Jeff Zaltman. "Together, we're working to create a mainstream platform in which innovation in electric propulsion can be developed, nurtured, and accelerated more rapidly."

Source: Airbus

Published February 2019
