Ford to develop electric vehicle based on Rivian's flexible skateboard platform, invests $500M in company

Do you remember that super-cool Rivian all-electric pickup we featured in Designfax last December? Ford Motor Co. has made a $500 million equity investment in Rivian, and the two companies have agreed to work together to develop an all-new, next-generation battery electric vehicle for Ford's growing EV portfolio using Rivian's skateboard platform.

Rivian, a new-kid-on-the-block electric vehicle manufacturer, introduced its R1T, an all-electric, five-passenger pickup at the LA Auto Show in December 2018. Featuring a tailored and restrained design, the truck boasts a range of up to 400+ miles, a wading depth of 1 m, quad-motor AWD that does 0 to 60 mph in 3 sec, and a totally unique skateboard platform with lots of storage.

Rivian has development centers in Plymouth, MI; San Jose, CA; Irvine, CA; and the UK. The company will produce vehicles at its modern, 2.6-million-sq-ft manufacturing plant in Normal, IL. First delivery target is late 2020.

Rivian is also developing a seven-passenger SUV called the R1S.

"As we continue in our transformation of Ford with new forms of intelligent vehicles and propulsion, this partnership with Rivian brings a fresh approach to both," said Jim Hackett, Ford president and CEO. "At the same time, we believe Rivian can benefit from Ford's industrial expertise and resources."

As part of a previously announced $11 billion EV investment, Ford already has confirmed two key, fully electric vehicles: a Mustang-inspired crossover coming in 2020 and a zero-emissions version of the best-selling F-150 pickup.

Rivian will remain an independent company. The investment is subject to customary regulatory approval. Following Ford's investment, Joe Hinrichs, Ford's president of Automotive, will join Rivian's seven-member board.

Source: Ford Motor Co.

Published May 2019
